JCPT1523RTL2Electric Slab Scissor LiftELECTRIC
JCPT1523RTL2 Electric Slab Scissor Lift
15.00m / 49ft 3inmWorking Height
7/7Occupants
Description
Equipped with integrated axle, they meet the requirements of 4WD&2WS, offer flexible operation and strong rough-terrain performance. The diesel model is equipped with low power engine, which is more energy-saving. With maximum load of 680kg and maximum working height of 18m, the large platform enables more than one people to work at the same time. They feature 4.88m*1.83m working platform and the two-way extension deck lengths are 1.43m and 1.13m respectively, which can be stopped at any point, making the operation more convenient. With configuration of one key leveling function, automatic leveling, ensuring the machine much safer and more stable.
Key Features
- Equipped with integrated axle, they meet the requirements of 4WD&2WS, offer flexible operation and strong rough-terrain performance.
- The diesel model is equipped with low power engine, which is more energy-saving.
- With maximum load of 680kg and maximum working height of 18m, the large platform enables more than one people to work at the same time.
- They feature 4.88m*1.83m working platform and the two-way extension deck lengths are 1.43m and 1.13m respectively, which can be stopped at any point, making the operation more convenient.
- With configuration of one key leveling function, automatic leveling, ensuring the machine much safer and more stable.
Specifications
Max. Working Height15.00m / 49ft 3in
Max. Platform Height13.00m / 42ft 8in
Overall Length(Without Outriggers)3.98m / 13ft 1in
Overall Length(With Outriggers)4.88m / 16ft
Overall Width2.33m / 7ft 8in
Overall Height(Rails Up)3.02m / 9ft 11in
Overall Height(Rails Down)2.26m / 7ft 5in
Platform Size(Length×Width)4.88m×1.83m / 16ft×6ft
Platform Extension Size1.43m/1.13m / 4ft 8in/3ft 10in
Ground Clearance(Stowed/Raised)0.30m / 1ft
Wheelbase2.86m / 9ft 5in
Turning Radius(Inside/Outside)2.70m/5.50m / 8ft 10in/18ft
Tyres315/55/D20
Safe Working Load680kg / 1499lb
S.W.L On Extension227kg / 500lb
Max. Occupants(Indoor/Outdoor)7/7
Gradeability0.4
Travel Speed(Stowed)≯5.0km/h / ≯3.10mph
Travel Speed(Raised)≯1.0km/h / ≯0.62mph
Max. Working Slope(X/Y)2°/3°
Up/Down Speed73/62sec
Overall Weight(Without Outriggers)7100kg / 15653lb
Overall Weight(With Outriggers)8000kg / 17637lb
Diesel EngineKubota D1105/18.2kW
Diesel Tank80L / 21gal
Hydraulic Tank120L / 31gal
Power SourceEngine
