GTBZ16SUTelescopic Boom Lift
GTBZ16SU Telescopic Boom Lift
₹ 1,30,28,400
+ 18% GST = ₹ 1,53,73,512 incl.
15.60m/51ft 2inmWorking Height
4Occupants
Description
Dingli’s Ultra Deck GTBZ16SU is equipped with a loading capacity of 1800 kgs and 6.70mx2.24m super large working platform. It enhances operational efficiency and eliminates extra trips to the ground, by elevating up to 4 workers with materials in one go. It is suitable for construction and other heavy-duty tasks.
Key Features
- Equipped with bridge Integrated four-wheel driving system
- Component downward design for enhanced stability
- All parts are located on both side of chassis for convenient maintenance
- 55.4kw High Power engine for long lasting performance
- One key levelling system
Specifications
Max. Working Height15.60m/51ft 2in
Max. Platform Height13.60m/44ft 7in
Max. Front Outreach(Outriggers Extension)8.46m/27ft 9in
Max. Rear Outreach(Outriggers Extension)4.66m/15ft 4in
Max. Platform Slide1.51m/4ft 11in
Overall Length7.35m/24ft 1in
Overall Width(Stowed)2.50m/8ft 2in
Overall Width(Transport)2.31m/7ft 7in
Overall Height(Rails Up)3.55m/11ft 8in
Overall Height(Rails Down)2.62m/8ft 7in
Overall Height(Transport)2.37m/7ft 9in
Platform Size(Length×Width)6.70m×2.24m/22ft×7ft 4in
Ground Clearance0.32m/1ft 1in
Wheelbase3.80m/12ft 6in
Turning Radius(Inside/Outside)2.45m/5.50m / 8ft/18ft 1in
Tyres355-55/D625
S.W.L1800kg/3968lb
Max. Goods Loading13350kg/29431lb
Max. Occupants4
Platform Swing Angle+/-90°
Gradeability40%
Travel Speed(Stowed)6.0km/h / 3.70mph
Travel Speed(Raised)0.9km/h / 0.56mph
Max. Working Slope3°/5°
Classis Leveling10°
Overall Weight13350kg/29431lb
Diesel EngineDeutz TD2.9 L4 55.4kW/2600rpm
Hydraulic Tank216L/57gal
Power SourceEngine
