GTBZ20SUTelescopic Boom Lift
GTBZ20SU Telescopic Boom Lift
20.30m/66ft 7inmWorking Height
4Occupants
Description
Dingli’s Ultra Deck GTBZ20SU enhances operational efficiency and eliminates extra trips to the ground, by elevating up to 4 workers with materials in one go. Equipped with a load capacity of 1350 kgs and 6.70mx2.24m large working platform, GTBZ20SU revolutionises construction and heavy-duty tasks.
Key Features
- Equipped with bridge Integrated four-wheel driving system
- Component downward design for enhanced stability
- All parts are located on both side of chassis for convenient maintenance
- 55.4kw High Power engine for long lasting performance
- One key levelling system
Specifications
Max. Working Height20.30m/66ft 7in
Max. Platform Height18.30m/60ft
Max. Front Outreach(Outriggers Extension)11.70m/38ft 5in
Max. Rear Outreach(Outriggers Extension)4.09m/13ft 5in
Max. Platform Slide2.19m/7ft 2in
Overall Length7.68m/25ft 2in
Overall Width(Stowed)2.46m/8ft 1in
Overall Width(Transport)2.30m/7ft 7in
Overall Height(Rails Up)3.80m/12ft 6in
Overall Height(Rails Down)2.89m/9ft 6in
Overall Height(Transport)2.59m/8ft 6in
Platform Size(Length×Width)6.70m×2.24m/22ft×7ft 4in
Ground Clearance0.37m/1ft 3in
Wheelbase4.00m/13ft 1in
Turning Radius(Inside/Outside)3.24m/4.97m / 10ft 8in/16ft 4in
Tyres385-65/22.5
S.W.L1350kg/2976lb
Max. Goods Loading900kg/1984lb
Max. Occupants4
Platform Swing Angle+/-90°
Gradeability40%
Travel Speed(Stowed)6.0km/h / 3.70mph
Travel Speed(Raised)0.9km/h / 0.56mph
Max. Working Slope3°/5°
Classis Leveling10°
Overall Weight18000kg/39683lb
Diesel EngineDeutz TD2.9 L4 55.4kW/2600rpm
Hydraulic Tank216L/57gal
Power SourceEngine
