OPT0507Oil-Free Scissor Lift
OPT0507 Oil-Free Scissor Lift
₹ 10,39,542
+ 18% GST = ₹ 12,26,660 incl.
4.99m/16ft 4inmWorking Height
1Occupants
Description
Small structure, flexible operations No noise, 0 emissions Minimum turning radius is 0m/1.3m (inside/outside wheel) Equipped with a 2X12V/115Ah strong lithium battery pack with integrated charger
Key Features
- Small structure, flexible operations
- No noise, 0 emissions
- Minimum turning radius is 0m/1.3m (inside/outside wheel)
- Equipped with a 2X12V/115Ah strong lithium battery pack with integrated charger
Specifications
Max. Working Height4.99m/16ft 4in
Max. Platform Height2.99m/9ft 10in
Overall Length1.59m/5ft 3in
Overall Width0.75m/2ft 6in
Overall Height1.59m/5ft 3in
Ground Clearance0.04m/2in
Wheelbase1.11m/3ft 8in
Turning Radius (Inside/Outside)0m/1.30m / 0in/4ft 3in
Wheels (Front)Φ254×63.5mm/Φ10in×3in
Wheels (Back)Φ305×63.5mm/Φ1ft×3in
Tyresφ381×127mm
S.W.L Of Platform (For Person)135kg/297lb
S.W.L Of Platform (For Goods-Up)90kg/198lb
S.W.L Of Platform (For Goods-Down)115kg/253lb
Max. Occupants1
Forward Speed (Stowed)4.80km/h / 3.0mph
Back Speed (Stowed)3.20km/h / 2.0mph
Travel Speed (Raised)1.30km/h / 0.80mph
Up/Down Speed18/18sec
Gradeability15%
Max. Working Slope0°
Overall Weight640kg/1410lb
Battery2×12V/115Ah
Charger24V/15A
Driving Motor2×24V/0.68kW
Lifting Motor24V/1.20kW
Power SourceElectric
