S0807ACElectric Slab Scissor LiftELECTRIC
S0807AC+ Electric Slab Scissor Lift (AC Drive)
7.80m/25ft 7inmWorking Height
2/1Occupants
Description
Designed for exceptional performance, reliability, and efficiency, the S0807AC+ sets the standard with a powerful set of features that make it a game-changer in the industry.
Specifications
Max. Working Height7.80m/25ft 7in
Max. Platform Height5.80m/19ft
Overall Length (With Ladder)1.86m/6ft 1in
Overall Width0.76m/2ft 6in
Overall Height (Rails Up)2.15m/7ft 1in
Overall Height (Rails Down)1.83m/6ft
Platform Size (Length × Width)1.67m × 0.74m / 5ft 6in × 2ft 5in
Platform Extension Size0.90m / 2ft 11in
Ground Clearance (Stowed / Raised)0.09m / 0.016m / 3in / 1in
Wheelbase1.36m / 4ft 5in
Turning Radius (Inside / Outside)0m / 1.64m / 0in / 5ft 5in
Tyresφ323×100mm
S.W.L272kg/600lb
S.W.L On Extension113kg/249lb
Max. Occupants2/1
Gradeability25%
Travel Speed (Stowed)5.5km/h / 3.41mph
Travel Speed (Raised)0.6km/h / 0.37mph
Max. Working SlopeX-1.5° / Y-3°
Up/Down Speed22/22sec
Overall Weight (Lead-acid Battery)1630kg / 3594lb
Overall Weight (Lithium Battery)1630kg / 3594lb
Hydraulic Tank7L
Battery28.8V/125Ah
Charger28V/30A
Driving Motor2×15VAC/0.5kW
Lifting Motor15VAC/3kW
Power SourceElectric
