S1008ACElectric Slab Scissor LiftELECTRIC
S1008AC+ Electric Slab Scissor Lift (AC Drive)
10.00m/32ft 10inmWorking Height
2/0Occupants
Description
The S1008AC+ is engineered for high performance, reliability, and energy efficiency, making it the ideal choice for demanding lifting tasks. Featuring a fully sealed AC system, this scissor lift ensures maintenance-free operation, superior safety, and long-lasting durability. With its advanced technology and environmental benefits, it delivers outstanding results while minimizing operational costs.
Specifications
Max. Working Height10.00m/32ft 10in
Max. Platform Height8.00m/26ft 3in
Overall Length (With Ladder)2.48m/8ft 2in
Overall Width0.83m/2ft 9in
Overall Height (Rails Up)2.36m/7ft 9in
Overall Height (Rails Down)1.90m/6ft 3in
Platform Size (Length × Width)2.27m × 0.81m / 7ft 5in × 2ft 8in
Platform Extension Size0.90m / 2ft 11in
Ground Clearance (Stowed / Raised)0.10m / 0.019m / 4in / 1in
Wheelbase1.87m / 6ft 2in
Turning Radius (Inside / Outside)0m / 2.10m / 0in / 6ft 11in
Tyresφ381×127mm
S.W.L272kg/600lb
S.W.L On Extension113kg/249lb
Max. Occupants2/0
Gradeability25%
Travel Speed (Stowed)6.0km/h / 3.73mph
Travel Speed (Raised)0.8km/h / 0.50mph
Max. Working SlopeX-1.5° / Y-3°
Up/Down Speed32/34sec
Overall Weight (Lithium Battery)2230kg/4917lb
Hydraulic Tank20L
Battery28.8V/150Ah
Charger28V/30A
Driving Motor2×15VAC/0.87kW
Lifting Motor15VAC/3.42kW
Power SourceElectric
