JCPT2814DCElectric Slab Scissor LiftELECTRIC
JCPT2814DC Electric Slab Scissor Lift
28.00m/91ft 10inmWorking Height
2Occupants
Description
Engineered for strength and efficient performance, JCPT2814DC is perfectly suited for environmentally demanding working conditions. This no noise, zero emission scissor lift has an overall width of 1.40m, and ensures good passability and multi-purpose versatility.
Key Features
- Drivable at full height with a large load of 750kg
- Automatic self-levelling for stability
- 4 Wheel driving and steering for flexibility
- Equipped with 80V/520Ah high-capacity battery pack
Specifications
Max. Working Height28.00m/91ft 10in
Max. Platform Height26.00m/85ft 4in
Overall Length(With Outriggers)5.69m/18ft 8in
Overall Width1.40m/4ft 7in
Overall Height(Rails Up)4.16m/13ft 8in
Overall Height(Rails Down)3.17m/10ft 5in
Platform Size(Length×Width)5.08m×1.20m/16ft 8in×3ft 11in
Platform Extension Size1.90m/6ft 3in
Ground Clearance(Stowed/Raised)0.19m/0.02m / 7in/1in
Wheelbase4.14m/13ft 7in
Turning Radius(Inside/Outside)2.50m/3.30m / 8ft 2in/10ft 10in
Tyres28×12-22
S.W.L750kg/1653lb
S.W.L On Extension750kg/1653lb
Max. Occupants2
Gradeability30%
Travel Speed(Stowed)1.5km/h / 0.93mph
Travel Speed(Raised)0.1km/h / 0.06mph
Max. Working Slope1°(0°)
Up/Down Speed115/95sec
Overall Weight(With Outriggers)18260kg/40256lb
Hydraulic Tank180L/47gal 5pt
Battery80V/520Ah
Charger80V/80A
Driving Motor4×53V/2kW
Lifting Motor53V/28kW
Power SourceElectric
