LEO27GTPLUSSpider Lift
LEO27GTPLUS Spider Lift
27,00 mmWorking Height
250 kgkgPlatform Capacity
Description
Designed with four innovative stabiliser positions for easy maneuvering and safety, LEO27GTPLUS comes with a 300 Kg lifting device. Compact with low surface load, LEO27GTPLUS is versatile, stable, and offers enhanced comfort to operators.
Key Features
- Boom design for maximum stability
- Low surface load with non-marking rubber tracks to protect sensitive surfaces
- Intuitive controls system
- Intelligent Teupen “FUZZY”
- High-performance stabiliser system
- Ascend/Descend inclines and staircases with ease.
Specifications
Working height, max.27,00 m
Platform height, max.25,00 m
Horizontal outreach, max. (100 kg)14,30 m
Horizontal outreach, max. (250 kg)12,50 m
Negative reach, max.5,00 m
Up and over clearance, max.12,00 m
Platform capacity, max.250 kg
Jib, movable165°
Platform, rotatable180 °
Turntable rotation, max.450 °
To be jacked up on ground slope of16,7 ° / 30.0 %
Track drive, height- and width-adjustable26 / 42 cm
Gradeability, max.16,7 ° / 30,0 %
Slope angle, max.16,7 ° / 30,0 %
Travel speed, max.2,5 km/h
Platform (height) (A)1,10 m
Platform (length) (B)1,40 m
Platform (width) (C)0,70 m
Length (D)6,45 m
Length without platform (E)6,45 m
Height (F)1,99 m
Width, min. (G)0,89 m
Ground clearance, max. (H)0,31 m
Track (length x width) (I)1,50 x 0,23 m
wide (lenght) (J) X (wide) (K)4,90 m / 4,70 m
narrow (lenght) (L) X (lenght) (M)6,50 m / 2,99 m
left or right narrow (width) (N)3,90 m
front or back narrow (lenght) (O)5,68 m
Outrigger plate Ø0,18 m
Total weight3870 kg
Live load in travelling position4,90 kN/m2
Live load in working position1,75 kN/m2
Point load per outrigger plate, max.29,00 kN
Electric motor(230 V, 12,9 A, 2,2 kW)
Combustion engine (Diesel)Kubota Z602 (10,8 kW / 14,5 hp)
Fuel tank capacity (Diesel engine)11,50 l
SeriesTeupen Leo Series
Power SourceDiesel / Electric
