LEO39GTPLUSSpider Lift
LEO39GTPLUS Spider Lift
38,60 mmWorking Height
32,00 lkgPlatform Capacity
Description
Designed for easy access and precision maneuvering, LEO39GTPLUS is a versatile spider lift equipped with intuitive controls and reliable safety settings. Engineered with height and width adjustable crawler tracks for stability and efficiency, LEO39GTPLUS is all set to ease outdoor and indoor operations with effortless ease.
Key Features
- Boom design for maximum stability
- Low surface load with non-marking rubber tracks to protect sensitive surfaces
- Intuitive controls system
- Intelligent Teupen “FUZZY”
- 4 platform sizes to choose from
- Ascend/Descend inclines and staircases with ease.
Specifications
Working height, max.38,60 m
Platform height, max.36,60 m
Horizontal outreach, max. (400 kg)18,30 m
Horizontal outreach, max. (300 kg)20,20 m
Horizontal outreach, max. (140 kg)23,30 m
Up and over clearance, max.21,00 m
Negativ reach, max.13,15 m
Platform capacitiy, max.400 kg
Jib, movable200 °
Platform, rotatable2 x 220 °
Turntable rotation, max.450 °
To be jacked up on ground slope of16.7 ° / 30.0 %
Track drive, height- and width-adjustable23 / 12 cm
Gradeability, max.16.7 ° / 30.0 %
Slope angle, max.16.7 ° / 30.0 %
Travel speed, max.3,0 km/h
Platform (height) (A)1,10 m
Platform (length) (B)1,50 m
Platform (width) (C)0,8 m
Length (D)7,85 m
Length without platform (E)7,00 m
Height (F)1,99 m
Width, min. (G)1,59 m
Ground clearance, max. (H)0,40 m
Track (length x width) (I)2,12 x 0,30 m
Outrigger footprint both side wide (length) (J)5,31 m
Outrigger footprint both side wide (width) (K)5,20 m
Outrigger footprint one side narrow (length) (L)7,30 m
Outrigger footprint one side narrow (width) (M)4,00 m
Outrigger footprint both sides narrow (width) (N)2,70 m
Outrigger plate (length x width)0,50 m x 0,22 m
Total weight8750 kg
Live load in travelling position6,60 kN/m2
Live load in working position3,25 kN/m2
Point load per outrigger plate, max.62,50 kN
Electric motor(country-specific 3-phases)
Combustion engine (Diesel)Kubota D1305 (18,0 kW / 24,47 PS)
Fuel tank capacity (Diesel engine)32,00 l
SeriesTeupen Leo Series
Power SourceDiesel / Electric
