LEO34GTPLUSSpider Lift
LEO34GTPLUS Spider Lift
34,10 mmWorking Height
32,00 lkgPlatform Capacity
Description
Equipped with innovative safety features and intuitive controls, LEO34GTPLUS is versatile enough to be used across a range of applications. Engineered with a high-performance stabiliser system and low surface load, this spider lift comes with a height and width adjustable crawler tracks to ease outdoor and indoor operations.
Key Features
- Boom design for maximum stability
- Low surface load with non-marking rubber tracks to protect sensitive surfaces
- Intuitive controls system
- Intelligent Teupen “FUZZY”
- 4 platform sizes to choose from
- Ascend/Descend inclines and staircases with ease.
Specifications
Working height, max.34,10 m
Platform height, max.32,10 m
Horizontal outreach, max. (400 kg)18,00 m
Horizontal outreach, max. (300 kg)18,90 m
Horizontal outreach, max. (140 kg)19,90 m
Up and over clearance, max.21,00 m
Negativ reach, max.9,20 m
Platform capacitiy, max.400 kg
Jib, movable200 °
Platform, rotatable2 x 220 °
Turntable rotation, max.450 °
To be jacked up on ground slope of16.7 ° / 30.0 %
Track drive, height- and width-adjustable23 / 12 cm
Gradeability, max.16.7 ° / 30.0 %
Slope angle, max.16.7 ° / 30.0 %
Travel speed, max.3,0 km/h
Platform (height) (A)1,10 m
Platform (length) (B)1,50 m
Platform (width) (C)0,8 m
Length (D)7,85 m
Length without platform (E)7,00 m
Height (F)1,99 m
Width, min. (G)1,59 m
Ground clearance, max. (H)0,40 m
Track (length x width) (I)2,12 x 0,30 m
Outrigger footprint both side wide (length) (J)5,31 m
Outrigger footprint both side wide (width) (K)5,20 m
Outrigger footprint one side narrow (length) (L)7,30 m
Outrigger footprint one side narrow (width) (M)4,00 m
Outrigger footprint both sides narrow (width) (N)2,70 m
Outrigger plate (length x width)0,50 m x 0,22 m
Total weight8210 kg
Live load in travelling position6,20 kN/m2
Live load in working position3,06 kN/m2
Point load per outrigger plate, max.57,70 kN
Electric motor(country-specific 3-phases)
Combustion engine (Diesel)Kubota D1305 (18,0 kW / 24,47 PS)
Fuel tank capacity (Diesel engine)32,00 l
SeriesTeupen Leo Series
Power SourceDiesel / Electric
